Joe
You cannot plug a QSFP-DD transceiver directly into an OSFP port because they have physically different form factors. To make this work, you need to use an OSFP to QSFP-DD adapter. Simply insert the adapter into your switch’s OSFP port, and then plug your QSFP-DD transceiver into the adapter.
Ross
While both modules support 400G data rates, OSFP modules are slightly wider and deeper than QSFP-DD modules, making them physically incompatible for direct insertion. However, the OSFP specification is designed to be backward compatible via an MSA-compliant OSFP to QSFP-DD mechanical adapter. By installing this adapter module into the OSFP slot, it provides the correct physical receptacle and electrical interface for your 400G QSFP-DD optic.
Harper
Direct insertion is not possible due to size differences, but you can achieve this connection by following these steps:
Obtain an Adapter: Purchase a compatible 400G OSFP to QSFP-DD adapter module.
Install the Adapter: Slide the adapter into the target OSFP port on your network switch until it is firmly seated.
Insert the Transceiver: Plug your 400G QSFP-DD transceiver directly into the receptacle on the adapter until it clicks into place.
Larry
No, direct insertion is not supported because OSFP ports are larger than QSFP-DD modules. You must purchase and install an OSFP to QSFP-DD adapter module to bridge the physical gap and allow the QSFP-DD transceiver to function properly in the OSFP slot.
Sarah
You cannot insert the module directly due to the different physical dimensions of the two form factors. You have two primary solutions:
- Module Adapter: Use an OSFP to QSFP-DD adapter to plug your existing QSFP-DD module into the OSFP port.
- Direct Attach Cables (DAC/AOC): If you are simply trying to connect an OSFP switch to a QSFP-DD switch, you can bypass transceivers entirely and use a dedicated 400G OSFP to QSFP-DD DAC or AOC cable, which has an OSFP connector on one end and a QSFP-DD connector on the other.
