Product Details
| Calix Compatible |
100-05583 | Vendor Name |
FiberMall |
| Application |
XGSPON OLT | ODN Class |
N2 |
| Wavelength |
TX 1577nm/RX 1270nm | Data Rate |
TX 9.95G/RX 9.95G/RX 2.488G |
| TX Power |
+4.0~+7.0dBm | Receiver Sensitivity |
<-29.5dBm(2.5G) <-28.0dBm(10G) |
| Package |
SFP+ | Interface |
SC/UPC |
| Cable Type |
SMF | Max Distance |
20km |
| Operation Temperature |
-40 °C to 85 °C | Protocols |
ITU-T G.987.2, G.9807.1 |
