Arista Networks QSFP-100G-SRBD Compatible Dual Rate 40G/100G QSFP28 BIDI 850nm & 900nm 100m LC MMF DDM Optical Transceiver

  • {{ detail_data.displayed_price.unit_prefix }}  {{ detail_data.displayed_price.value }}

    {{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}

{{comment.count}} Reviews
SKU:17954
{{ detail_data.displayed_price.unit_prefix }}  {{ detail_data.displayed_price.value }} {{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.original_price }} ({{ detail_data.displayed_price.rate_of_discount }}% OFF) {{detail_data.displayed_price.ex_sell_type}}
FM PN:
QSFP28-100G-SRBD
Ship From:
Asia
Shipping:
{{ detail_data.displayed_price.unit_prefix }} {{now_chooseship.price}}
Free Shipping
Can't deliver
to United States Via {{now_chooseship?now_chooseship.name:''}}
Estimated delivery time : 3-5 working days. See details
Quantity:
( Min. Order {{detail_data.prodInfo.minimum_ordered_quantity}} )
Total Price:
{{detail_data.currency.unit_prefix}} {{detail_data.displayed_price.total}}
{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.original_total_price }} ({{ detail_data.displayed_price.rate_of_discount }}% OFF) {{detail_data.displayed_price.ex_sell_type}}

Arista Networks QSFP-100G-SRBD Compatible Dual Rate 40G/100G QSFP28 BIDI Optical Transceiver (850nm & 900nm MMF 100m LC DDM)

The 40G/100G QSFP28 BIDI supports dual rate 40Gb/s and 100Gb/s bit rates. It is a parallel QuadSmall Form-factor Pluggable (QSFP28) Bi-Direction optical module. The module integrates four host electrical data into two optical lanes (by Dual Wavelength VCSEL Bi-Directional Optical Interface, 850nm, and 900nm) to allow optical communication over a 2-fiber duplexLC optical multi-mode fiber.

Product Details

Arista Networks Compatible QSFP-100G-SRBDVendor Name FiberMall
Form Factor QSFP28Max Data Rate 40Gbps/100Gbps
Wavelength 850nm & 900nmMax Distance 100m
Connector Duplex LCTransmitter Type 850/900nm VCSEL
Cable Type MMFReceiver Type PIN
TX Power -6.0~+4.0dBmReceiver Sensitivity <-8.0dBm
Chip Manufacturers BroadcomModulation Format PAM4
Protocols 100G Ethernet, QSFP28 MSA CompliantOperation Temperature 0 to 70°C (32 to 158°F)


Quality Assurance

Excellent quality is the foundation of FiberMall' s survival and development. Our operation team are experts with many years' experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.

Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

our advantages

Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

Keep In Stock

Fast Delivery
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

Professional Service

Technical Support
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

Worry-Free Guarantee

Shopping Satisfactorily
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

Premium Quality

High stability

Rigorous Industrial ProductTesting

Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably

Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

Temperature Impact

High and low temperature cycle,aging test to ensure good temperature characteristics
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

Mechanical Impact

Mechanicalvibration testing to ensure the stability of products
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

EMI Testing

Excellent designand rigorous testing ensuregood EMI performance
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall

MTBF Testing

MTBF(Mean Time between Failures)testing ensure high stablility

100% 3rd Party Compatible

FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
Coding(EEPROM Programming)
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
Testing system

Partial test demonstartion

Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
Cisco N9k-C92160YC-X-C
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
HP ProCurve 5406zl J8697A
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
ARISTA 7-50QX-32
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
Juniper EX4300
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
HW S5700-28X-L1-AC
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
Brocade VDX 6720
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
DELL S4048 ON
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
DATACOM DM4100
Arista QSFP-100G-SRBD Compatible 100G QSFP BIDI Optics | FiberMall
H3C LS-5500-28C-S
Arista Networks Compatible
QSFP-100G-SR4
QSFP-100G-SRBD
Vendor Name
FiberMall
FiberMall
Form Factor
QSFP28
QSFP28
Max Data Rate
103.1Gbps
40Gbps/100Gbps
Wavelength
850nm
850nm & 900nm
Max Distance
100m on OM4
100m
Connector
MTP/MPO-12
Duplex LC
Transmitter Type
850nm VCSEL
850/900nm VCSEL
Cable Type
MMF
MMF
Receiver Type
PIN
PIN
TX Power
-8.4~+2.4dBm
-6.0~+4.0dBm
Receiver Sensitivity
< -10.3dBm
<-8.0dBm
Protocols
100G Ethernet, MSA Compliant
100G Ethernet, QSFP28 MSA Compliant
Operation Temperature
0 to 70°C (32 to 158°F)
0 to 70°C (32 to 158°F)

Product Features

v Compliant to the 100GbE XLPPI electrical specification per IEEE 802.3bm

v Compliant to QSFP28 SFF-8636 Specification

v Dual-wavelength VCSEL bi-directional optical interface, PAM4 2 × 50-Gb/s 850nm/900 nm

v QSFP28 MSA compliant

v Capable of over 70m transmission on OM3 Multimode Fiber (MMF)and 100m on OM4 MMF

v Single +3.3V power supply operating

v RoHS Compliant Part

v Supports 100 Gigabit Ethernet interconnects, Datacom/Telecom switch & router connections, Data aggregation and backplane applications, and Proprietary protocol and density applications
