Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
  • Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
  • Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
  • Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
  • Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
  • Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
  • Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
  • Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
Add to wish

Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver

Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver

  • $  180.00

    Available

5 Reviews
SKU:17960
$  180.00
Compatible
Cisco
FiberMall
Arista Networks
Avago Broadcom
EdgeCore
Huawei
Juniper
Mellanox
Ruijie Networks
Transceiver Variant
QSFP-100G-DR-S
QSFP-100G-FR-S
QSFP-100G-LR-S
QSFP-100G-ERL-S
FM PN:
QSFP28-100G-DR1
Ship From:
Asia
Shipping:
$ 29.66
to United States Via DHL
Estimated delivery time : 3-5 working days. See details
Quantity:
Total Price:
$ 180.00

Cisco QSFP-100G-DR-S Compatible 100G QSFP28 PAM4 Single Lambda DR Optical Transceiver (1310nm SMF 500m LC with FEC DDM)

The 100Gbase DR incorporates one channel optical signal, on 1310nm center wavelength,  operating at a 50Gbaud data rate.  A DSP-based gearbox is used to convert 4x25Gbps NRZ signals to 1x50Gbaud PAM4 signals.  The electrical interface is compliant with IEEE 802.3cd and QSFP28 MSA in the transmitting and receiving directions, and the optical interface is compliant with IEEE 802.3cd and 100G Lambda MSA with a Duplex LC connector. The module has a maximum power consumption of 3.5W.

Product Details

Cisco Compatible QSFP-100G-DR-SVendor Name FiberMall
Form Factor QSFP28Max Data Rate 100Gbps Single Lambda
Wavelength 1310nmMax Distance 500m
Connector Duplex LCTransmitter Type EML
Cable Type SMFReceiver Type PIN
TX Power -2.4~+4.0dBmReceiver Sensitivity < -4.4dBm
DDM Support YESFEC Support YES
Protocols IEEE802.3cd 100GBASE-DR, 100G Ethernet, MSA CompliantOperation Temperature 0 to 70°C (32 to 158°F)

Quality Assurance

Excellent quality is the foundation of FiberMall's survival and development. Our operation team are experts with many years' experience in the optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certifications, such as ISO 9001, CE, RoHS, FCC, etc.

Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

our advantages

Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

Keep In Stock

Fast Delivery
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

Professional Service

Technical Support
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

Worry-Free Guarantee

Shopping Satisfactorily
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

Premium Quality

High stability

Rigorous Industrial ProductTesting

Optical communication products are industrial products that require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials, and production technology to ensure the first-class quality of our products so that your project can be used, installed stably, and reliably

Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

Temperature Impact

High and low-temperature cycle, aging test to ensure good temperature characteristics
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

Mechanical Impact

Mechanical vibration testing to ensure the stability of products
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

EMI Testing

Excellent design and rigorous testing ensure good EMI performance
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall

MTBF Testing

MTBF(Mean Time Between Failures)testing ensures high stability

100% 3rd Party Compatible

FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices. Before shipment, We will code the optical modules or DAC/AOC cables, and then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
Coding(EEPROM Programming)
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
Testing system

Partial test demonstartion

Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
ARISTA 7060SX2-48YC6
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
H3C S6850-56HF
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
Cisco N9K-C92160YC-X
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
HP JG510A
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
Juniper QFX5110-48S-AFO
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
Mellanox SN4700
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
Cisco-N9K-C93600CD-GX
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
NVIDIA QM9790
Cisco QSFP-100G-DR-S Compatible Single Lambda 100G DR1 | FiberMall
Ruijie RG-S6990-128QC2XS
Cisco QSFP-100G-LR-S Compatible 100G QSFP28 Single Lambda LR 1310nm 10km LC SMF with FEC DDM Optical Transceiver
QSFP28-100G-LR1
Cisco QSFP-100G-FR-S Compatible 100G QSFP28 Single Lambda FR 1310nm 2km LC SMF with FEC DDM Optical Transceiver
QSFP28-100G-FR1
Cisco QSFP-100G-DR-S Compatible 100G QSFP28 Single Lambda DR 1310nm 500m LC SMF with FEC DDM Optical Transceiver
QSFP28-100G-DR1
Cisco QSFP-100G-ER4L-S Compatible 100G QSFP28 ER4 Lite1310nm (LAN WDM) 40km with FEC,30km without FEC LC SMF DDM Transceiver Module
QSFP28-100G-ER4L
Cisco Compatible
QSFP-100G-LR-S
QSFP-100G-FR-S
QSFP-100G-DR-S
QSFP-100G-ER4L-S
Vendor Name
FiberMall
FiberMall
FiberMall
FiberMall
Form Factor
QSFP28
QSFP28
QSFP28
QSFP28
Max Data Rate
100Gbps Single Lambda
100Gbps Single Lambda
100Gbps Single Lambda
103.1Gbps
Wavelength
1310nm
1310nm
1310nm
1295.56nm, 1300.05nm
1304.58nm, 1309.14nm
Max Distance
10km
2km
500m
30km without FEC
40km with FEC
Connector
Duplex LC
Duplex LC
Duplex LC
Duplex LC
Transmitter Type
EML
EML
EML
LAN WDM EML
Cable Type
SMF
SMF
SMF
SMF
Receiver Type
PIN
PIN
PIN
APD
TX Power
-1.4~+4.5dBm
-2.4~+4.0dBm
-2.4~+4.0dBm
-2.9~+4.5dBm
Receiver Sensitivity
< -4.5dBm
< -4.5dBm
< -4.4dBm
<-16.9dBm without FEC
<-20.9dBm with FEC
DDM Support
YES
YES
YES
-
FEC Support
YES
YES
YES
-
Protocols
100G Lambda MSA 100G-LR, 100G Ethernet
100G Lambda MSA 100G-FR, 100G Ethernet
IEEE802.3cd 100GBASE-DR, 100G Ethernet, MSA Compliant
100G Ethernet, MSA Compliant
Operation Temperature
0 to 70°C (32 to 158°F)
0 to 70°C (32 to 158°F)
0 to 70°C (32 to 158°F)
0 to 70°C (32 to 158°F)
  1. 100G QSFP28 DR
  2. 100Gbase DR

Resources

Related Info

Questions & Answers

 Ask a Question
No data

Customer Reviews

 Write a Review
  • 5

    5 reviews

  • 5 Stars
    100%
    4 Stars
    0%
    3 Stars
    0%
    2 Stars
    0%
    1 Star
    0%
E***n
United States
Verified Purchase
5.0
2023-05-30
The modules arrived quickly and worked perfectly in pre-deployment testing. Deployment should be complete by the end of the week and I don't anticipate any issues.
5 Helpful vote Comments
C***n
United States
Verified Purchase
5.0
2023-03-29
We are using these transceivers in the lab for 100G direct connectivity. Typically, FiberMall's optics work consistently and reliably. These 100G single lambda modules are no exception. Overall, using these new transceivers can be a great experience.
5 Helpful vote Comments
N***e
United States
Verified Purchase
5.0
2023-03-04
I have experience with Cisco and Juniper switches. Recently, I bought two 100 GB modules. Fortunately, both modules worked within two days of purchase. I am happy to report that my network is running smoothly with the new modules.
5 Helpful vote Comments
T***n
United States
Verified Purchase
5.0
2023-02-25
Used for a two building system about 500 meters away. I installed the 100G module on my unit and it was up and running from the moment I turned it on. So far I have not seen any problems.
5 Helpful vote Comments
O***n
United States
Verified Purchase
5.0
2023-02-12
Due to the high demand for 100G modules for our data center connectivity, I purchased some cheap DR modules locally and kept losing packets. After purchasing the FiberMall modules, I had a great experience with them as they were largely trouble free in terms of connectivity.
5 Helpful vote Comments
